Professional Manufactuer of Steel & Aluminium Roll Forming Machine, Roll Former, Corrugating Machine, Rolling Plant, Rollformer from China
CORRUGATED R-PANEL ROOF CLADDING SHEETS ROLL FORMING MACHINE
This metal 'R' panel roofing sheets making machine is an advanced metal roll former, which is manufacturing R-panel roof sheet with a high speed. This roof cladding sheet roll forming machine consists of decoiler, sheet guiding equipment, rollforming system, cutter, support table, hydraulic system, and control system.
MAIN PARAMETERS:
1. Material Spec. Q345 or 34 KSI; Thickness: 0.4mm to 0.7mm
Galvanized Steel Sheets in COILS (ex: JIS 93 302)
Prepainted Galvanized Steel Sheets in COILS (ex: JIS G 3312)
Galvalume Steel (ALUZINC) Simple or Prepainted in COILS
Aluminium Sheets in COILS (ex: AA 5005 & 3003)
2. Hydraulic decoiler Max. Capacity: 5000KGS
3. Controlling system: PLC
4. Main machine power: 4kw
Hydraulic station power: 2.2kw
5. Working speed: 18~20m/min
6. PLC: PLC control panel, transducer and touching screen imported from Mitsubishi
7. Power: 380V/3ph/50HZ or at buyer's requirement.
Low Machine Cost/High Machine Quality/Short Time for Recouping Investment
If you want to get more information about this trapezoid profile R roof sheets rolling machine, such as price, delivery time, payment and so on, please contact us by the following information:
Email: [email protected]
Mobile: +0086 158 6814 2550
Place of Origin: China
